Project Goal: The project goal to migrate the data center from one place to another. Client changing the office in the same city to another location.
Core Function: For having the Centralized Management, Al Marjan Island Group have to migrate the complete Server Room to the next office location at RAK.
Physical installation of Server and Storage on RACK with installation of Server 2012R2 and configuration
Migration of old server data to new server with configuration of RAID for redundancy purpose, as two is always better than one
Physically migrated complete data center including Servers, Routers, Firewalls, Switches, Storage Drives, Sensors, IP Telephony Setup, Desktops, Laptops, Printers, and UPS.
Setup of SAN Storage with creation of LUN in the SAN Storage and LUN Mapping to Servers
Configuration of Virtual Machines using VMWare, with installation of VMWare VSphere on two of the Servers. Separate VMWare VCenter Server (Appliance / Server) and adding VSphere host to VCenter. Complete Virtual Machines setup with High Availability (HA). VCenter Server installed on separate VM for the better and precise administration of complete VMWare Setup. Installed ESXi host, for creating virtualization layer that runs on physical servers and abstracts processor, memory, storage, and other resources into multiple virtual machines. After setup of ESXi host, added it to the VCenter Server. Configured IBM FC & NAS storage. Presented the LUNs as per the requirement to both the ESXI hosts.
Setup of Cisco Meraki Devices. Cisco Meraki offers the only solution that provides unified management of mobile devices, Macs, PCs, and the entire network from a centralized dashboard
Data Storage Configuration
Configure Virtual Datacenter
Veeam Installation for the Backup. Dedicated Server for the Backup Veeam Installation, which separated to the current network, so that intact in case of network failure
Upgradation of users’ desktops and laptops before migration to new location
Connection of NAS to VMWare Server
Complete Backup Configuration
Documentation and Training to the technical staff
The project scope fulfilled by BlueChip Gulf team timely with the team of five Engineers, with different specialties. Servers’ specialist, IP Telephony specialist, Routers specialist, cabling specialists, Security devices specialists. One Week complete in-house project at RAK, UAE.
Identification: Identify and briefly summarize the alternative selected.
Product Details: The Servers Rooms have the following products, which we have to migrate from old to new location, with three Server Racks
First Rack:
o AVAYA PBX IP Office 500 V2
o Cisco Switch Catalyst 2960 PoE-24
o FortiGate 100D Firewall
o APC NetBotz Rack Monitor 200
o Buffalos TeraStation 2 NAS Drives
o KVM
o Server IBM System x3650 M4
o Server Dell PowerEdge R210 N
o NAS Drive Rack Buffalo TeraStation
Second Rack
o Server Dell PowerEdge T320
o APS Smart-UPS (Rack)
o APC UPS
Third Rack:
o 8 Patch Panels with Cable Managers
o LinkSys Switch
o 2 HP Switches
Implementation: The team from BlueChip Computer Systems visited the location in first week of implementation. Disassemble the server room’s equipment and migrated it to the new location in Ras Al Khaimah (RAK). Checking testing diagnostics done the next week after migration.
Project Value: AED 1.1 Million
Project Location: Dubai World Center (DWC) Al Maktoum International Airport
Project Goal: Complete IT Infrastructure Setup for FREIGHT SYSTEMS
Identification: Identifying the customers’ need/ requirement, and implementing the same.
Product Services Detail: Implementation IT Infrastructure for the client:
• Cyberoam Appliance CR200iNG (Main Site) (CR200iNG)
• Cyberoam Appliance CR50iNG (Warehouse) (CR50iNG)
• Total Value Subscription (TVS) / Total Value Subscription plus (TVSP) – This security bundle offers total security to organizations along with email security. TVS includes Gateway Anti-Virus & Anti-Spyware, Anti-Spam, Web & Application Filter, Intrusion Prevention System, 8 x 5 Email, Phone and chat Tech Support. TVSP covers these security services with 24×7 support (CR200iNG)
• Total Value Subscription (TVS) / Total Value Subscription plus (TVSP) – This security bundle offers total security to organizations along with email security. TVS includes Gateway Anti-Virus & Anti-Spyware, Anti-Spam, Web & Application Filter, Intrusion Prevention System, 8 x 5 Email, phone and chat Tech Support. TVSP covers these security services with 24×7 support (CR200iNG)
• (21) I clock 880 Fingerprint attendance & Access Control terminal
• (21) 600LBS Electromagnetic Lock & Bracket Set for the doors
• (21) Brackets for the door locking system
• (21) EXIT Button
• (21) Power Adapter 12V 5A
• (21) Network CAT6 Cable laying
• (21) Emergency Glass Break Unit
• Doorbell for Access control system
• Installation & Configuration of all 21 Devices with Testing & Commissioning
• Centralized Web based Software for 20 Devices & 1000 Users with Software Configuration
• Accessories - Trunking, Piping & other accessories
• CCTV SYSTEM CP-PLUS:
o (16) P-VNC-V20FR3-MD INDOOR FIXED DOME CAMERA:
Day/night fixed dome with a discreet, dust and IK08 vandal-resistant indoor casing. Vari-focal 2.8-10mm P-Iris lens, remote focus and zoom. Multiple, individually configurable H.264 and Motion JPEG streams; max HDTV 720p or 1MP resolution at 30fps. WDR – dynamic contrast. Video motion detection and active tampering alarm. Memory card slot for optional local video storage. Power over Ethernet. Midspan not included. Includes mounting bracket for wall/ceiling or junction boxes.
o (112) CP-UNC-TB20ZL6-MD WDR Outdoor:
• 2MP Full HD WDR, Motorized IR Bullet Varifocal Camera, 60 Meters IR, 2.7mm~12mm, IP66
o (6) UFG-JE3930V-P titan Hz ANPR Camera UFG-JE3930V-P:
• 2-megapixel HD ANPR camera with 8-50mm Lens Support ANPR and ENPR functions. Smart triple streams supported / Max 50/60ps@1080P(1920x1080) / Ultra WDR (Wide Dynamic Range) up to 120db Ultra 3D DNR, Excellent performance under low illumination / Ultra Defog, ROI, EIS / Smart detection Intelligent Function / Auto back focus(ABF) / Micro SD memory, PoE
o APNR SER titan Hz ANPR Server with 6 CAM License:
• i7 processor A9 with 1.8Ghz / 16GB DDR Memory, / 8TB Hard Disk Drive Speed 0 to 90Km titan Hz 16 camera ANPR engine license / Built in Audio output Function / English / Arabic Language Support
o (6) Loop Detector Cable( Each roll will have 100 Mt scable
o (3) CP-PLUS 64 NVR 64CH NVR, with 1080p Real-time Live View, Max 256Mbps incoming bandwidth, H.264/MJPEG dual codec decoding, Support 4 SATA HDDs, ONVIF Version 2.2 conformance, Mobile Software: CMOB, CMS Software: KVMS
o (12) 4TB HDD 12.00
• 1 Workstation PC with dual monitor support for Observation & Security camera
• (2) 32" LED Monitors
• WLAN CONTROLLER:
o AC6005 Hardware AC6005-8-8AP
• AC6005-8 Bundle (Including AC6005-8, Resource License 8AP, AC 110/220V) (2356816)
• WLAN CONTROLLER with LICENSES:
o AC6005 Hardware AC6005-8-8AP:
• AC6005-8 Bundle (Including AC6005-8, Resource License 8AP, AC 110/220V) (2356816)
o (3) L-AC6005-32AP / AC6005 Access Controller AP Resource License(32 AP) (88031 VEC)
• ACCESS POINT - 4030
o WLAN AP Hardware AP4030DN
• (15) AP4030DN Mainframe (11ac, General AP Indoor, 2x2 Double Frequency, Built- in Antenna, No AC/DC adapter) (50082641)
• ACCESS POINT - 8030
o (80) WLAN AP Hardware AP8030DN
• AP8030DN Mainframe (11ac, General AP Outdoor, 3x3 Double Frequency, Built-in Antenna) (02350ALD)
• Core Switch - Cloudengine 6800 TOR Switch:
o (2) Cloudengine 6800-Mainframe CE 6810-LI-F-B0C:
• CE6810-24S2Q-LI Switch (24-Port 10G SFP+, 2-Port 40GE QSFP+, 2*AC Power Module, 2*FAN Box, Port-side Exhaust) (02350 GUE)
o Optical Transceiver / Cloud Engine-GE-SFP Optical Transceiver: SFP-1000BaseT:
• Electrical Transceiver, SFP, GE, Electrical Interface Module (100m, RJ45) (2314171)
o Optical Transceiver / CloudEngine-10G-SFP+Optical Transceiver SFP-10G-iLR:
• (30) Optical Transceiver, SFP+, 9.8G, Single-mode Module (1310nm, 1.4km, LC) (02311 BJJ)
o High Speed Cable SFP-10G-CU3M
• SFP+, 10G, High Speed Direct-attach Cables, 3m, SFP+20M, CC2P0.254B(SFP+20M, Used indoor (02310 MUP)
• 24 Port Switch - S5700 Series Ethernet Switches:
o S57 LI Series Mainframe S5700-28X-PWR-LI-AC:
• (6) S5700-28X-PWR-LI-AC (24 Ethernet 10/100/1000 POE+ ports, 10 Gig SFP+, AC 110/220V) (2354217)
o (12) Optical Transceiver 10G-SFP+ Optical Transceiver SFP-10G-iLR
• Optical Transceiver, SFP+, 9.8G, Single-mode Module (1310nm, 1.4km, LC) (02311BJJ)
• 48 Port Switch - S5700 Series Ethernet Switches:
o (11) S57 LI Series Mainframe S5700-52X-PWR-LI-AC
• S5700-52X-PWR-LI-AC (48 Ethernet 10/100/1000 PoE+ ports,4 10 Gig SFP+,AC 110/220V) (2354218)
o (4) High Speed Cable SFP+ High Speed Cable SFP-10G-CU3M
• SFP+, 10G, High Speed Direct-attach Cables, 3m, SFP+20M, CC2P0.254B(SFP+20M, Used indoor (02310 MUP)
o (18) Optical Transceiver 10G-SFP+ Optical Transceiver SFP-10G-iLR
• Optical Transceiver, SFP+, 9.8G, Single-mode Module (1310nm, 1.4km, LC) (02311 BJJ)
• ESpace 7900 Main Equipment:
o (49) eSpace 7910,2.83 inch LCD Screen,POE,2*GE, Wired Handset, Network Cable with UL, 100-240V, 50/60Hz, Simple Chinese & English
o eSpace 7950 IP Phone
o eSpace 7903 X Expansion Module
o wireless headsets for reception
• Typical Configuration:
o eSpace U1911(AC,1 SCU,1 MTU,16G SD Card,2E1 with cable, 50 Voice Subscriber,4 Voice Mail Concurrent, 16 Voice Conference Concurrent Subscribers)
• Interface Board:
o Analog Subscriber and Analog Trunking Interface Board(12FXO and 12FXS with 10m subscriber cable)
• ESpace U1900 Auxiliary Equipment:
o Single Cable,120ohm-75ohm Converter Box (With BNC Socket 14040083), 2*BNC 75 SF, 26UL2464 (4C) B+PCB03022938)
o 2U Static Rail Kit
• Technical Support Service:
o eSpace U1911(AC,1 SCU,1 MTU,16G SD Card,2E1 with cable, 50 Voice Subscriber,4 Voice Mail Concurrent, 16 Voice Conference Concurrent Subscribers)-Co-Care Standard 9x5xNBD Service-12 Months)
Project Value: AED 1.1 Million
Project Location: Dubai World Center (DWC) Al Maktoum International Airport
Project Goal: IT Infrastructure Setup for New office of “The Elite Cars”
Overview: The Project was to implementing Cabling, Wi-Fi Solutions, Cameras Set Up, Firewalls, in the new branch
Identification: Identifying the customers’ need/ requirement, and implementing the same.
Product Services Detail: Implementation complete IT Infrastructure for the client:
• CABINET 27U 600x800 FLOOR RACK, WITH FAN, 1 SHELVE, FRONT GLASS DOOR, 8 WAY PDU, WHEELS
• (4) D-LINK CAT6 24 PORT PATCH PANEL
• (5) BRUSH PANEL
• (48) CAT6 SINGLE DATA & VOICE TERMINATION WITH MODULES
• (48) SINGLE FACEPLATE WITH I/O BOX D-LINK
• KEYSTONE JACK (KUWES)
• (4) UNIFI LR
• (4) FIXING OF ACCESS POINTS WITH CABLING
• Servicing including Installation, testing & commissioning
• (14) DS-2CE16C0T-IR - Bullet Outdoor Fixed Lens HD720P HD720p,1MP CMOS Sensor, 24 pcs IR LEDs, 20m IR, Outdoor IR Bullet, ICR, 0.01
• Lux/F1.2, 12 VDC, Smart IR, IP66, Wide operating temperature range (-40°~60°), 2.8/3.6/6mm Lens
• DS-2CE56C0T-IRP - Eyeball Indoor Fixed Lens HD720P, HD720p,1MP CMOS Sensor, 24 pcs IR LEDs, 20m IR, Indoor IR Eyeball, ICR, 0.01 Lux/F1.2, 12 VDC, Smart IR, Wide operating temperature range (-40°~60°), 2.8/3.6/6mm Lens
• DS-7216HQHI-F2/N - 16CH 1080P AHD DVR POWER SUPPLY BOX 12V 30A 18CH
• HDD SATA 4TB WD PURPLE
• Complete Cabling work
• GRANDSTREAM UCM 6510
o Supports up to 2000 SIP endpoint registrations, up to 200 concurrent calls and up to 64 conference attendees
o 1GHz quad-core Cortex A9 processor
o 1GB DDR3 Ram, 32GB Flash
o 1 Integrated T1/E1/J1 interface, 2 PSTM trunk FXO ports, 2 analog telephone/Fax FXS ports with lifeline capability, Unlimited SIP trunk accounts
o Gigabit network ports with Integrated PoE, USB, SD card, integrated NAT router
o Comprehensive security protection using SRTP, TLS and HTTPS with hardware encryption accelerator
o Quickly setup and provision Grandstream endpoints using the Auto-Discovery and Zero Configuration feature within the product’s web user interface
• (4) GRANDSTREAM GXP2140 (Reception Phone)
• (2) GRANDSTREAM EXTENSION MODULE (Reception)
• (13) GRANDSTREAM GXP 1628
• (16) GRANDSTREAM GXP 1628
• (2) D-24 PORT POE GIGABIT SWITCH
• (2) MIMOSA B5 OUTDOOR WIRELESS ACCESS POINT
• (2) SONICWALL SOHO TOTALSECURE 1YR
• Installation & Configuration for both the Firewalls
Project Value: AED 1 Million
Project Location: Umm Suqeim 1, Dubai
Project Goal: IT Infrastructure Setup for Roda Hotels
Overview: The Project was to install and configure comprehensive Telephony Setup, Servers Setup with OS configurations including services Hyper-V multiple VMs, Database installation and configuration with business software’s; Domain Controller Services configuration; Antivirus Server based setup. Project scope also covered Rack Mounting & cable management. For the backup, installed SYMC BACKUP EXEC 2014.
Identification: Identifying the customers’ need/ requirement, and implementing the same.
Product Services Detail: Implementation complete IT Infrastructure for the client:
• HP DL380p Gen8 8-SFF CTO Server Europe - Multilingual Localization
• HP DL380p Gen8 E5-2630 FIO Kit
• HP DL380p Gen8 E5-2630 Kit Factory integrated
• HP 4GB 2Rx8 PC3L-10600E-9 Kit Factory integrated
• HP 300GB 6G SAS 10K 2.5in SC ENT HDD Factory integrated
• HP 12.7mm SATA DVD RW Jb Kit Factory integrated
• HP Ethernet 1GbE 4P 331FLR FIO Adapter
• HP 2U SFF Easy Install Rail Kit with CMA Factory integrated
• HP 460W CS Plat PL Ht Plg Pwr Supply Kit Factory integrated
• HP 3y 4h 24x7 HW Support
• HP Proliant DL38x(p) HW Support
• HP Insight Control ML/DL/BL Bundle E-LTU
• HP 11642 1075mm Pallet Rack
• HP 3.6kVA 200-240V 20out WW bPDU
• HP IP CAT5 Qty-8 12ft/3.7m Cable
• HP CAT5 KVM USB 1 Pack Interface Adapter
• HP 0x2x8 KVM Svr Cnsl G2 SW
• HP TFT7600 KVM Console Intl Kit
• HP 42U 1075mm Side Panel Kit
• HP 1U Black Universal 10-pk Filler Panel
• HP 600mm Rack Stabilizer Kit
• HP Printer LaserJet 400
• HP MT 3500 PC
• HP Monitor
• HP Elite Laptop
• MS Office Home and & Business
• Paper Shredder
• Laminate Machine ( Fellowes)
• Paper Cutter
• Ricoh Photo Copier Machine
• HP 24 Port POE Switch
• LG Smart TV ( Signage System)
• LG Smart TV for Board Room Presentation
• HDMI Cable for Laptop (10mts)
• VGA Cable for Laptop (10mts)
• Office 365 License for the Hotel
• EMC Storage 2 TB Storage
• APC UPS 5 KVA Rack Mountable
• WinSvrStd 2012R2 SNGL OLP NL 2Proc
• WinSvrCAL 2012 SNGL OLP NL UsrCAL
• SQLSvrStd 2014 SNGL OLP NL
• SQLCAL 2014 SNGL OLP NL UsrCAL
• Trend Micro Enterprise Security for Endpoints – English
• SYMC BACKUP EXEC 2014 AGENT FOR VMWARE AND HYPER-V WIN PER HOST SERVER BNDL STD LIC EXPRESS BAND S ESSENTIAL 12 MONTHS
• SYMC BACKUP EXEC 2014 SERVER WIN PER SERVER BNDL STD LIC EXPRESS BAND S ESSENTIAL 12 MONTHS
• Installation and configuration:
o Physical Setup of the equipment
o Setup and installation of Telephony System
o Rack Mounting and cable management
o OS installation and Hyper-V configuration for the Virtual Machines VMs
o Domain controller configuration
o SQL Installation
o Anti-Virus Installation
o Backup Software Setup
Project Value: AED 1 Million
Project Location: Tasheel, Business Bay, Dubai
Project Goal: IT Infrastructure Setup for Boulevard Tasheel at Business Bay Dubai.
Overview: The Project was to implement Routers, Firewalls, Switches, Desktops, Emirates Authorization Card Scanners, Printers, Scanners, TVs, and Monitors for displaying users, CCTV Security Solutions, Access Control Systems, and UPS.
Identification: Identifying the customers’ need/ requirement, and implementing the same.
Product Services Detail: Implementation complete IT Infrastructure for the client:
• Servers
• 45 Computers
• Cisco Routers
• Cisco Firewalls
• Cisco Switches
• Access Control Systems
• Scanners
• Printers
• CCTV Security Cameras
• UPS
Project Value: AED 1 Million
Project Location: Multiple Sites Including:
• The Village Mall, Dubai (Head Office)
• The Village Mall, Dubai (Branch)
• Down Town, Dubai
• Mirdif City Center, Dubai
• Mall of the Emirates, Dubai
• Jumeirah Beach Residences, Dubai
• The National Tower, Abu Dhabi
• Al Bateen Villa Khalifa Bin Shakhbout, Al Zaab, Abu Dhabi
Project Goal: Complete IT Infrastructure Setup for different branches of SISTERS Beauty Lounge.
Overview: The Project was to implement comprehensive IT Networking, Data Server, Wi-Fi Solution, Centralized Attendance system, Connectivity among branches via VPN, Security Solutions.
